Product Description

UPS FEATURES

HIGH POWER EFFECTIVENESS
• It is designed with 0.9 output PF and ≥0.98 input PF (1-3kVA); ≥0.99 input PF (6-10kVA), thus high power effectiveness.

EXCELLENT RELIABILITY
• Designed with DSP technology and tropicalized costed PCBs for maximum reliability.

USER FRIENDLY ADJUSTABLE PARAMETERS
• With proprietary computer monitoring software (MTR), voltage; frequency; Battery EOD voltage; UPS shutdown and shutdown timing setting; battery testing; transfer & re-transfer etc, can be set and adjusted to achieve the maximum desire UPS performance.

UPS PARALLELING
• 6kVA & 10kVA can be paralleled up to 3 units to achieve redundancy and power capacity.

USER FRIENDLY LARGE LCD DISPLAY
• LCD display segment can rotate 90° to ease readout easier in rack or tower installation; all electrical measurements and power consumption can be read from the display.

EXTENDED BATTERY RUNTIME
• Optional battery pack is available to increase battery runtime for hours in case of emergency.

BUILT-IN MANUAL BYPASS
• 6K & 10K UPS is designed with standard built-in manual bypass breaker, thus ensuring businese continuation even if UPS is at service and manintenance.

HIGH PERFORMANCE, HIGH EFFICIENCY
• The New 6K/10K PF1 UPS delivers 11.1% higher power than previous model. AC/AC efficiency is up to 95% making the New 6K/10K PF1 UPS one of the highest efficiency in its class, and efficiency is up to 98% at ECO mode.

INTELLIGENT FAN SPEED CONTROL
• The New 6K/10K PF1 UPS is featured with automatic fan speed regulation dependent on load rate, input voltage & working mode.

DIGITAL CONTROL, FLEXIBLE BATTERY MANAGEMENT
• The New 6K/10K PF1 UPS is designed with fully digitized flexible battery management system, battery quantity for KS model can be adjusted at user friendly mimic panel range from 16, 18, 20, 22, & 24 blocks of 12V battery and charging current range from 1A, 2A, 3A, 4A & 5A dc.

SELF AGING, POWER CIRCULATION FEATURE
• The New 6K/10K PF1 UPS is featured with this function to enable simulation of UPS testing can be done without load connected.
